- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpower.com/au
- Brand Name
- CyberPower
- Product Series
- Switched PDU
- Marketing Information
The CyberPower PDU41004, a 1U rackmount switched power distribution unit (PDU), provides 100-240V 15A output via 8 IEC-320 C13 receptacles from a single IEC-320 C14 input power plug. The switched outlet receptacles can be managed over the network by using the CyberPower Management Console, a web browser, and the RJ45 Ethernet port for network connection, or locally from the Power Control display. The PDU41004 offers outlets that can be turned on, turned off, or recycled on demand. Outlets can be programmed to address a number of needs including remote rebooting of locked equipment, load shedding, power sequencing, and locking out unauthorized loads.
With a three-year limited warranty, you can trust CyberPower's commitment to high quality.
- Product Type
- PDU
- Technical Information
- PDU Type
- Switched
- Phase
- Single Phase
- Plug/Connector Type
- IEC 60320 C14
- Plug/Connector Detail
- 1 x IEC 60320 C14
- Receptacle Type
- IEC 60320 C13
- Receptacle Detail
- 8 x IEC 60320 C13
- Locking Receptacles
- Cord Retention Tray
- Features
- LCD Display
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Input Voltage Range
- 100 V AC - 240 V AC
- Output Voltage
- 120 V AC
- 230 V AC
- Output Voltage Range
- 100 V AC - 240 V AC
- Input Current
- 15 A
- Input Frequency
- 60 Hz
- Management
- Management
- IPv4
- TCP/IP
- UDP
- SNMPv1
- HTTP
- NTP
- DNS
- Telnet
- DHCP
- SMTP
- FTP
- IPv6
- SNMPv3
- HTTPs
- SSH
- SSL
- TLS
- LDAP(S)
- RADIUS
- Syslog
- CLI
- Windows AD
- Remote Outlet Switching
- Yes
- Interfaces/Ports
- Network (RJ-45)
- Yes
- USB
- Yes
- Physical Characteristics
- Colour Family
- Black
- Product Colour
- Black
- Product Material
- Metal
- Mounting Orientation
- Horizontal/Vertical
- Mount Type
- Rack-mountable
- Form Factor
- Rack
- Rack Height
- 1U
- Cord Length
- 3.05 m
- Height
- 44.4 mm
- Width
- 112 mm
- Depth
- 433.1 mm
- Weight (Approximate)
- 2.10 kg
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 60°C
- Minimum Storage Temperature
- -15°C
- Maximum Storage Temperature
- 65°C
- Miscellaneous
- Additional Information
- Adjustable Mounting Brackets: 2 sets (L-Short, L-Long)
- Controllable Outlets: 8
- Cord Retention Tray/Cord Organizers: Yes
- Derated Input Current: 12 A
- Environmental Sensor: Optional, via RJ45
- External Site Ground Pin: Yes
- Input Frequency Range: 50 Hz - 60 Hz
- Plug Style: Straight
- LED Indicators: Tx/Rx
- Meter Readout: Power Control Display
- Modular Expandability (Cascading): Yes, via RJ45
- Storage Elevation: 0 - 49213 ft (0 - 14999 m)
- Outlets - Front: 8
- Outlets - # of Banks: 1
- Outlets - Rear: 0
- Outlets - Total: 8
- Overload Protection: None
- USB Charge Port: No
- Upgradeable firmware: Yes
- Operating Elevation: 0 - 11483 ft (0 - 3500 m)
- Operating Relative Humidity: 0 - 95 % (non-condensing)
- Energy Star?
- No
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- UL Listed
- Yes
