- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpower.com/au
- Brand Name
- CyberPower
- Marketing Information
The CyberPower PDU20MVHVIEC24F, a 24-outlet (front), 0U vertical rackmount basic power distribution unit (PDU), provides 200/230V 20A output. It distributes power to 20 IEC-320 C13, 4 IEC-320 C19 receptacles from a single IEC-320 C20 plug with unfiltered electrical pass-through. The current draw for connected equipment is displayed in amps on the front LCD for real-time load monitoring.
- Product Type
- PDU
- Technical Information
- Receptacle Type
- IEC 60320 C19
- Receptacle Detail
- 4 x IEC 60320 C19
- Protection Type
- Overload Protection
- Power Description
- Output Voltage
- 230 V AC
- Output Voltage Range
- 200 V AC - 230 V AC
- Input Current
- 20 A
- Input Frequency
- 60 Hz
- Physical Characteristics
- Colour Family
- Black
- Product Colour
- Black
- Product Material
- Metal
- Mounting Orientation
- Horizontal/Vertical
- Mount Type
- Wall-mountable
- Rack Height
- 0U
- Cord Length
- 3.05 m
- Height
- 1219.2 mm
- Width
- 44.4 mm
- Depth
- 57.2 mm
- Weight (Approximate)
- 2.99 kg
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 35°C
- Minimum Storage Temperature
- -15°C
- Maximum Storage Temperature
- 45°C
- Miscellaneous
- Additional Information
- Adjustable Mounting Brackets | 3 sets (L-Short, L-Long, Flat)
- Cord Retention Tray/Cord Organizers | Yes
- External Site Ground Pin | Yes
- Meter Readout | Amperage
- Operating Elevation | 0 - 10000 ft (0 - 3048 m)
- Operating Relative Humidity | 0 - 95 % (non-condensing)
- Outlets - Front | 24
- Outlets - Rear | 0
- Outlets - Total | 24
- Overload Protection | 16A
- Plug Style | Straight
- Storage Elevation | 0 - 50000 ft (0 - 15239 m)
- USB Charge Port | No
- Style | Rackmount
